Elves Falath EXPERT 2025 | UCI-Approved Aero Road Bike Frame | Elves Bikes
Delivery 5 - 8 Weeks (Frames painted from Raw)
EVO AERO BARS not included.
Looking for a Custom Paint Work go here to create
Introducing the brand new 2025 Elves Falath EXPERT (Falath EXP) – the latest generation of our best-selling aero road racing frame. UCI-compliant and built with cutting-edge aerodynamics, enhanced comfort, and an updated T47 threaded bottom bracket, the Falath EXP is engineered for peak performance on every ride.
Falath EXP Specification Overview:
* Frame material: Toray T800 & T1000 Carbon Fibre - EPS Mounding Technology
* UCI approved (ELVES-FEXP)
* Weights: Please see below
* Full internal cable routing* Max Tyre Clearance: 700cx32mm
* Rotor Size: 140mm or 160mm Not supplied
* Bottom Bracket: Supplied - Threaded T47 Senicx Ceramic in a choice of Shimano 24mm, SRAM DUB 28.99 or 30mm - not fitted.
* Gear Mech Hanger: 2 x Supplied - Standard (not UDH)
* Thru-axles: Supplied - 100mm (front) & 142mm (rear)
* Seat post: Supplied - 10mm offset, 245mm in length, 190g, two way adjustable clamp (7x7mm & 7x10mm clamps supplied)
* Headset: Supplied
* Di2 battery mount: Supplied
* Brakes: Flat mount, rear 20mm depth (33mm bolts required - Shimano)
* Compatibility: Compatible with mechanical and electronic 10/11/12 speed groupsets inc Di2 & AXS (Di2 battery is housed in the down tube)
Designed for Pure Speed, Comfort and Control
Building on the worldwide success of the Falath Evo, the Falath EXP redefines what’s possible in an aero road bike. With next-generation aerodynamic technology, superior vibration damping, and enhanced stiffness, this frame is crafted for riders who demand the very best.
Aerodynamic Excellence
The Falath EXP features our revolutionary Inverted Triangle Airflow Channel (ITAC) – a precisely engineered rear triangle formed between the seatstays and seat tube. This channel significantly reduces drag, lowers turbulence, and optimises airflow, allowing you to slice through the wind with maximum efficiency.
Unmatched Comfort and Performance
The unique inverted triangle design doesn’t just boost aerodynamics – it also enables controlled vertical flex of the seatpost. By absorbing road vibrations without compromising frame stiffness, the Falath EXP delivers a smoother, more comfortable ride, especially over rough terrain. With clearance for tyres up to 32mm wide, you'll enjoy extra grip, stability, and speed no matter where the road leads.
High-Performance Materials & Advanced Engineering
Toray T800 & T1000 Carbon: Lightweight, strong, and responsive, reinforced in critical zones (bottom bracket, headtube) for optimal stiffness and durability.
EPS Moulding Technology:
Ensures a flawless internal frame structure, eliminating weak spots like folds or wrinkles for maximum strength and long-term reliability.
T47 Bottom Bracket:
The latest in bottom bracket design, offering improved bearing alignment, easier maintenance, and superior power transfer.
Rider-Centric Design Philosophy
Designed in collaboration with DSD Design House in Hong Kong and shaped by direct rider feedback, the Falath EXP is not only high-performing but also highly personalisable. Every frame comes with the option for custom paint at no extra cost, allowing you to ride a bike that’s as unique as you are.
Included accessories:
- T47 bottom bracket (choice of specification)
- Headset
- Handlebar spacers
- Two derailleur hangers
- Front and rear thru-axles
- Di2 battery holder
- Internal cable dampeners
Ride with Confidence – Global Warranty Included
At Elves Bikes, rider safety and satisfaction come first. Every Falath EXP frame is backed by our:
- 5-Year Global Warranty on frames
- 2-Year Warranty on handlebars and wheelsets
- 1-Year Warranty on saddles
We are proud to offer industry-leading quality at prices that challenge the norm, ensuring you no longer have to choose between performance and affordability.
Discover the Future of Aero Road Bikes with the 2025 Elves Falath EXPERT
Inspired by you. Created by us.
Ride faster, ride farther, ride Elves.
